Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket

Product Categories
Shenzhen Bede Mold Co., Ltd
Contact Now

Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket

Brand Name : BEDE

Model Number : BEDE-AISG-DB9

Certification : UL CE ROHS

Place of Origin : China

MOQ : 100

Price : $0.99

Payment Terms : Western Union , T/T ,Papay

Supply Ability : 20000/week

Delivery Time : 2 days for retail, 20 days for wholesale

Packaging Details : 1000 pcs in a carton, size 480*410*410mm, G.W. 25KG.

Type : Plastic Connector

Protection Level : IP 67/68

Function : waterproof

Material : PA66 UL94V-0

colour : black

Contact Now

AISG Cable Waterproof Plug D-SUB Connector IP68 Waterproof Grade Communication Cable Socket

Description
1,Waterproof rating IP68/67
2,Comply with RoHS and REACH standards
3,Rated voltage: 300V
4,Insulation resistance: ≥1000MΩ
5,Rated current: 5A
6,Contact resistance: ≤10mΩ
7,Ambient temperature: -25°C~ + 70°C
8,Contact: brass plated
9,Coupling nut/screw: brass nickel plated

Click To Download DB-TDS.pdf

Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket

Model specification

Name Factory Model Standards
DB9 Connector BEDE BEDE-AISG-DB9 RoHS

Parameter

Name Material Plating
Plastic connector PA66 UL94V-0 /
Size 4.1cm*2.2cm*25cm /
Pinhole brass 1.27um Ni bottom, gold plated contact 0.02-0.03um, fogging in the tail area Tin 2.5um
　
installation Screw
Size 30.8(A)*25(B)*12.5(C)*2.29(D)
Pins No. 15
Button /
Operating temperature 　-55℃～125℃
Rated voltage /
Rated current 　3A
Withstand voltage 　1000VAC,60s,1mA
Insulation resistance ≥5000MΩ
Contact resistance ≤30mΩ
Contact form 　welding
Lifetime 500 cycles
Storage conditions Normal temperature and humidity, no corrosive gas environment
Storage time 5 years
How to buy
PayPal and WestUnion is welcome, after payment (Products and Freight), please sent the Bank Bill to us,we will arrange the delivery within 2 days and inform you the logistics information.For large quantities more than 10000pieces, please feel free to contact us for whlesale price.
Contact Paypal Western Union
Name Alice Chu alicechu@szbede.com First name: CAIXIA
whatsapp +8618938686395 Last name: CHU
Mobile +8618938686395 Address: Xinqiao Street,Bao'an District, Shenzhen, China
Office +8675527084976
Eamil alicechu@szbede.com


Product Tags:

control cable assembly



control cable connectors


Quality Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket wholesale

Waterproof Plug D SUB Male Plug Connector Plastic IP68 Communication Cable Socket Images
